Horsepower: 475HP-770HP
Displacement: 2.0L-3.5L

Compressor
Compressor Inducer: 57.6mm
Compressor Exducer: 71.3mm
Compressor Trim: 65
Compressor A/R: 0.72
Compressor Air Inlet : 4 Inch
Compressor Air Outlet: 2 Inch

Turbine
Turbine Inducer: 60mm
Turbine Exducer: 55mm
Turbine Trim: 84
Turbine A/R: 0.61
Turbine Inlet : 3 Inch O.D. V-Band
Turbine Outlet: 3.55 Inch (90mm)O.D. w/81mm centering ring V-Band
Cooling Type: Water+Oil Cooling
Bearing Type: Dual Ceramic Ball Bearing
Oil Restrictor Size: 1mm
Oil Inlet Size: 7/16-24
Oil Outlet Size: φ13.5-2*M8*1.25
Water Thread Size: M14*1.5
